Industrial-Grade Device for Efficient Polishing Abrasive Finishing Vibratory Finishing Machine
Automated Process Integration Solution for Die Casting Finishing
This 150L automatic discharge vibratory polishing machine is purpose-built for high-volume automated surface finishing of die castings and hardware components, integrating an automatic discharge system with standard vibratory polishing functions—helping manufacturers achieve seamless connection between grinding and subsequent washing/drying processes, reduce manual material handling, and elevate production line automation.
Automatic Discharge System–Eliminates Manual Media Separation, Boosts Workflow Efficiency
Traditional vibratory polishing machines require manual separation and retrieval of workpieces from media after finishing—a labor-intensive process that disrupts continuous operation. This machine integrates an automatic discharge mechanism that, upon completion of the grinding cycle, automatically separates and discharges workpieces from media through vibration and screening principles. Workpieces proceed directly to washing or drying—eliminating manual retrieval and handling, shortening batch turnaround time, and significantly improving overall workflow efficiency.
150L Large Capacity–Ideal for Scalable Volume Production
With 150L capacity processing 200–250kg per batch, this machine is ideal for casting facilities, automotive parts suppliers, and hardware manufacturers requiring medium-to-large batch continuous operation—maximizing equipment utilization and reducing per-piece processing costs.
Three-Dimensional Vibratory Finishing–Efficient Deburring, Chamfering & Surface Smoothing
Employing high-frequency three-dimensional vibration technology, workpieces and media create spiral tumbling motion—delivering efficient removal of parting line flash, edge burrs, and oxide scale while providing an excellent substrate for subsequent electroplating or powder coating.
High-Wear PU Lining + Intelligent Control–Stable, Reliable, Easy Operation
The container features high-wear polyurethane (PU) integrally cast lining for impact and corrosion resistance; equipped with electrically controlled automatic discharge system and variable frequency speed control, with adjustable grinding time and discharge rhythm to suit different workpieces and process requirements.
With automatic discharge + process integration as your drivers, achieve labor reduction and continuous production upgrade in your post-casting finishing line.
|
|
Industrial-Grade Device for Efficient Polishing Abrasive Finishing Vibratory Finishing Machine Images
|
